- Pump DesignTri-plex 600GPM
- Rated Capacity600 U.S.Gallons (2,067 L)/min.
- Bore x Stroke6 x 6 in. (152.4 x 152.4 mm)
- Maximum Pressure1,505psi (1043 bar)
-
Mud motors offer the proven way to get acceptable penetration rates when drilling in hard formations and rock. The mud pump has to supply the mud motor, but also has to flush the cuttings to the surface for disposal. The table below shows typical flow rates for popular size mud motors. Be sure to allow enough extra mud flow to flood the bore. American Auger’s mud pumps can be used with any brand or size of a directional drill.
-
Mud motors offer the proven way to get acceptable penetration rates when drilling in hard formations and rock. The mud pump has to supply the mud motor, but also has to flush the cuttings to the surface for disposal. The table below shows typical flow rates for popular size mud motors. Be sure to allow enough extra mud flow to flood the bore. American Auger’s mud pumps can be used with any brand or size of the directional drill.
- Length20 ft. (6.096 m)
- Height9 ft. (2.7 m)
- Width8 ft. (2.49 m)
- Remote ControlsMud Pump Throttle, Mud Pump Start/Stop, Clutch Actuator, Horn remote
- Remote InstrumentsDigital Mud Flow Meter (gallons/liters per minute)
| Mud Motor Size (Inch) | 3-3/8 | 3-1/2 | 4-3/4 | 6-3/4 |
| Mud Motor Size (Millimeter) | 85.72 | 88.9 | 120.6 | 171.4 |
| Flow Rate (GPM) | 30-120 | 75-200 | 100-250 | 300-600 |
| Flow Rate (LPM) | 113.6 – 454.2 | 283.9 – 605.7 | 378.5 – 946.4 | 1,136 – 2,271 |
- Total Weight29,800 lbs. (13,520 kg) estimated
- EngineCaterpillar© C-15 Tier III Diesel *Tier III or Tier 4i determined by country of purchase
- Rating475 HP (354 kW)
- Maximum Speed2100 RPM
- Noise Rating1 Meter Distance 104 dB(A) 3 Meter Distance 95 dB(A)
- Fuel Capacity300 U.S. Gallons (1,136 L)
- TransmissionEaton-FRO-16210B, 10 Speed
- Clutch15.5 in. (394 mm) Twin Disk
- Battery(2) Deka 908DMF 12V,1450 CCA
-
- Pulsation Dampener on inlet and discharge
- (2) 25 ft. (7.6 m) suction hoses with 6 in. (152.4 mm) Kamlok Fittings
- (2) 25 ft. (7.6 m) Discharge Hoses with 3 in. (76.2 mm) NPT Hammer Unions
- Liner Wash System w/Supply Tank
- 24 V Work Lights
FEATURES
- Allows the operator to get enough flow to keep the bore flushed clean of cuttings
- Designed with a compact skid mounting and provides a small footprint that is the ideal form for most drilling conditions
- Compatible with any drill brand making it suitable for contractors operating a variety of sizes, makes and models of drilling equipment
- New! Tri-plex 600GPM Pump with Rated Capacity of 600 US gallons (2,067 L) / minute
- Caterpillar C-15 Tier III diesel engine
*Tier III or Tier 4i determined by country of purchase - Stand-alone, self-powered and compatible with any drill brand
Product Option
- Quiet-Pak® sound deadening enclosure
